VS-ST303C12CFK0 1200V 300A IGBT Module Low Vce(sat) Low Loss High Ruggedness Integrated NTC Fast Switching For Industrial Drives and UPS Inverters
Features
-
Power Rating: 1200V / 300A
-
Advanced IGBT and Diode Chips
-
Low Vce(sat) (Low Conduction Loss)
-
Optimized Switching Performance
-
High Short-Circuit Ruggedness
-
Integrated NTC Temperature Sensor
-
Low-Inductance Package Design
-
Industrial Grade Reliability
Applications
-
Industrial Motor Drives: For controlling pumps, fans, and compressors.
-
Uninterruptible Power Supplies (UPS): Three-phase UPS inverters and systems.
-
Solar Inverters: String and central inverters for photovoltaic systems.
-
Welding Equipment Power Supplies.
Description
The VS-ST303C12CFK0 is a robust 1200V, 300A IGBT module designed for reliable and efficient performance in medium-power industrial applications. Utilizing advanced IGBT and freewheeling diode technology, it achieves a low collector-emitter saturation voltage (Vce(sat)) to minimize conduction losses and offers optimized switching characteristics for controlled switching losses. The module is built for industrial durability, featuring a high level of short-circuit ruggedness and an integrated negative temperature coefficient (NTC) thermistor for accurate thermal monitoring and system protection. Its balanced performance and rugged construction make it a dependable choice for demanding power conversion circuits.
Technical Specifications
| category | Discrete semiconductor products thyristors SCR | |
| manufacturer | Vishay General Semiconductor - Diodes Division | |
| series | | |
| Packaging | | |
| Part status | | |
| Voltage - Fault state | | |
| Voltage - Gate Trigger (Vgt) (Max) | | |
| Current - Gate Trigger (IGT) (Max) | | |
| Voltage - On-State (Vtm) (Max) | | |
| Current - On-State (It (AV)) (Max) | | |
| Current - Normal State (It (RMS)) (Max) | | |
| Current - Hold (Ih) (max) | | |
| Current - Fault State (Max) | | |
| Current - Non-repeating surge 50, 60Hz (Itsm) | | |
| SCR type | | |
| Operating temperature | | |
| Mounting type | | |
| Package/Enclosure | | |
| Vendor device packages | | |
| Base product number | ST303 |
